ADVANTAGES OF HEAT PUMPS

Hot water in all weather conditions regardless of sunshine
Up to 7 months of the year you can use the pool. Bathe longer than others - Even during the spring and autumn months
Easy installation and operation
Save your own costs and nature (environmentally friendly and environmentally friendly heating)
Digital control panel with intuitive operation
Up to 83% free heat from the surroundings
For every 1 kWh you put in, you get up to 5 kWh free from the ambient air, and that's a big saving - considering the rising cost of electricity, pool heat pumps are a really good investment
In comparison, electric direct heaters are powerful, independent of the sun, but expensive to run - for 1 kW of electricity you only get 1 kW of heat energy

PRINCIPLE OF OPERATION OF THE HEAT PUMP

The heat pump enables heat to be extracted from the air around the pool by means of a cycle of compression and expansion of the heat transfer fluid. The air is propelled by a fan through an evaporator where it transfers its heat to the heat transfer fluid (cooling the air in the process). The heat transfer fluid is then transported by a compressor, which compresses and heats it, to the heat exchanger coils where it transfers its heat to the pool water. From the heat exchanger, the cooled fluid flows to the expansion valve where it is depressurised and rapidly cooled. This cooled fluid flows back into the evaporator where it is heated by the flowing air. The whole process is continuous and monitored by pressure and temperature sensors.

More Information
Digital display:	No
Cooling	No
Recommended pool volume, m3	11
Defrosting	No
Voltage, V	230/50
El. expansion valve:	No
Net weight, kg	20
Net dimensions, mm	360 x 355 x 410
Operating Power, kW	0,5
Flow monitoring:	No
For sea water:	No
Pressure circuit welded with silver:	No
Recommended water flow rate, (m³/h)	1,5 - 4
Gross weight,kg	22
Digital control panel:	No
Max. heat output, kW	3,2
Diameter of inlet/ outlet waterpiping, mm	32 or 38
Optional touch screen	✓
Noise at 1 m, dB(A)	36
Easy to install:	No
Package dimensions, mm	990 x 390 x 650
Operating temperature	No
