ZODIAC eXO® iQ LS 10, up to 40 m3

EXO® iQ LS - unit for salt water treatment with recommended salinity of 2g/l

Zodiac EXO® iQ LS is a system that can autonomously generate chlorine (salt electrolysis) just like Ei2 or Ei2 Expert. However, the EXO® iQ LS unit can be expanded with the "pH Link" or "Dual Link" optional module.

• pH Link enables pH regulation and dosing
• Dual Link enables both pH regulation and dosing, as well as ORP regulation

The Zodiac EXO® iQ LS system can be remotely controlled via WIFI connection and the iAqualink app. The app allows you to monitor the current state of water parameters, change desired parameters, and control associated devices (lights, filtration, counter-current, ...)

You can connect the following devices to this unit:

• Filter pump
  • Single-speed (any)
  • Variable speed - ZODIAC FloPro VS

• AUX1 - Lights
  • You can control any WHITE lights - ON/OFF
  • You can control RGB lights (ZODIAC) - the program is preset to ZODIAC NL's light color schemes

• AUX2 - Heat pump
  • The heat pump is controlled via a contactor (must be purchased separately)
  • You can set heating according to filtration times or activate "TEMPERATURE PRIORITY" - every 120 minutes, the heat pump starts the filtration circuit, measures the water temperature, and if it is lower than desired, the filtration pump remains in operation for the time necessary to heat the pool.

Recommended pool volume - up to 40 m³ -> with a minimum filtration time of 8 h/d

Zodiac® EXO iQ LS 10 has IP43 protection and a maximum chlorine production of 10g/h for private pools up to 40 m³ (8h/d)

• Backlit 4-line LCD display
• User interface in CZ, EN, DE, ...
• "BOOST" function (100% power - 24h) and "LOW" function (10% power - 24h)
• Flow switch
• Timer
  • Setting the chlorine production time (2 timers can be set)
  • Setting for single-speed pumps (2 timers)
  • Setting for variable speed pumps (4 timers)
  • 1 timer for other associated devices
• Polarity reversal every 5 hours (can be set from 2h to 8h)
• Cell lifespan: up to 10,000 hours
• Temperature sensor for electrolytic cell protection and water temperature measurement (in case of heat pump connection)
• It is recommended to keep the unit permanently connected to the power supply (to power the battery that maintains the timer memory in case of a power outage)

Warranty period for probes (not conditional) -

• ORP probe - 1 year (not included in the package - DUAL Link is required)
• pH probe - 2 years (not included in the package - pH Link or DUAL Link is required)

In the package:

• EXO iQ LS unit
• Cell
• Mounting kit for the wall
• Flow detection kit - flow switch
• Set with temperature sensor
• Reduction kit
